PRODUCT DETAILS
- Redline Proprietary 6061 T6 Alloy Formed Tubing, Integrated HT, Euro BB
- RL Mini/JR Fork 100% Full Chromo Steerer with Tapered Legs
- Redline Fully Sealed Aluminum Rear Cassette Hub, Fully Sealed Front Hub
- Redline Microline 3pc, Cranks
- Redline Microline Seat/Post combo
- Tioga Power Block Tires
Recommended Rider Height:Â 3′ 10″ – 4′ 8″
|
Top Tube |
 17.5″ |
|
Head Angle |
 72° |
|
Seat Angle |
 69° |
|
BB Height |
 10.5″ |
|
Chainstay |
 12.5″ |
Â
|
Frame |
 Proprietary Alloy Formed and Butted Tubing |
|
Fork |
 Full Chromo With Tapered Legs |
|
Colors |
 White/Orange |
|
Headset |
 Sealed Integrated 1″ |
|
Stem |
 RL Mini Aluminum HollowPoint 40mm |
|
Handlebar |
 RL Mini Aluminum 2.5″ 10° Back x 2° Up |
|
Grips |
 RL Mini Hex Grips |
|
Seat |
 RL Microline Seat/Post Combo 22.2 Aluminum post |
|
Seat Post |
 |
|
Seat Post Clamp |
 |
|
Rims |
 Alex R450, 20 x 1 1/8, 28h |
|
Front Hub |
 Redline Aluminum Fully Sealed |
|
Rear Hub |
 Redline Aluminum, Cassette , Fully Sealed |
|
Spokes |
 Stainless 14g, Black |
|
Tires |
 Tioga PowerBlock 20 x 1-1/8″ Tires |
|
Crankset |
 RL Microline 3pc 140mm,Cranks |
|
Bottom Bracket |
 Sealed Euro BB |
|
Pedals |
 Redline Jr Aluminum Platform / Chromo Spindle |
|
Brake |
 Tektro 926AL Linear |
|
Brake Lever |
 Tektro |
|
Chain |
 KMC Z33 |
|
Gearing |
 38t, Alloy, 110 BCD, 14t cogset |
|
Extras |
 Redline Chain Tensioners |
Weight:Â
