PRODUCT DETAILS
- 6061 series alloy frame with PTC (Power Transfer Center), integrated head tube, triple butted air formed top tube – 21.75″, over sized triple butted down tube, BB86 bottom bracket shell, tapered stays and 3D dropouts with integrated chain tensioners
- Box X-10 Pro Carbon fork with 1 1/8″ chromoly steer tube
- 100% chromoly 5.25″ bars and Haro CNC alloy front load stem
- 2-piece alloy 175mm cranks with sealed press fit BB86
- Fully sealed wheels with 24″ Alienation PBR rims, a sealed 18t rear cassette hub and alloy nipples
- Promax Click clamp on grips
- Promax “P-1” V-brake and “V-Point” brake lever
- Kenda Konversion 24 x 1.75″ tires
- Box Echelon plastic seat/carbon seat post combo
| Geometry | Head Angle | Seat Angle | Top Tube | Seat Tube | Chainstay | BB Height | Stand Over |
| Inches | 73.3° | 71° | 21.75 | 10.49 | 15.62 | 12 | 23.58 |
| MM | 73.3° | 71° | 553 | 266.5 | 397 | 305 | 599 |
Â
| Frame Components | |
| Frame | 6061 alloy with integrated head tube and PTC – 21.75″ TT. |
| Fork | Box X-10 Pro Carbon fork w/1 1/8″ crmo steer tube |
| Colors | SG Metallic Grey, |
| Drivetrain | |
| Cranks | 2-pc alloy 175mm / Sealed bearing press-fit BB86 |
| Gearing | 40/18 |
| Pedals | Haro DX Alloy |
| Wheels | |
| Tires | Kenda “Konversion” K1079 F/R 24×1.75 |
| Hubs | 36h Alloy Shell sealed bearing; 36h Alloy Shell sealed bearing cassette |
| Rims | Alienation PBR Alloy 36H 24″ |
| Braking System | |
| Rotor | N/A |
| Other Components | |
| Grips | Promax Click clamp on grip 130mm |
| Handle Bar | Crmo 5.25″ rise / Haro Alloy CNC front load 52mm ext |
| Seat | Box Echelon plastic seat/carbon post combo 27.2mm |
| Pegs | N/A |
Additional Information
| Barcode | 135454 |
|---|---|
| Special Shipping Group | Oversized_Items |
//
