CCH Super Cup Aluminum BMX Race Frame-Candy Red

CCH Super Cup Aluminum BMX Race Frame-Candy Red

Original price was: $489.95.Current price is: $93.99.

SKU: cch-3526844383304 Categories: FRAMES, Race Frames Tags: 26380828744out-of-stock, Bmx-frames, Bmx-frames-race, Bmx-race-frames, Cch, Discontinued, Discountable, Frames

Elevate Your Shopping Experience
The quality solution for all your needs.
Safeguard Your Shopping Experience
Your needs, our top priority.

PRODUCT DETAILS

The CCH Racing Super Cup BMX race frames are U.S.A. Made from 6061 seamless aluminum tubing and heat-treated to T-6 hardness for improved strength and stiffness. The frames feature aggressive racing geometry, oversized tubing, unique CCH wishbone design, and their exclusive “closed-loop” boxed chainstay.

FEATURES:
*Seamless 6061 T-6 heat-treated tubing
*U.S.A. Made
*CCH wishbone design
*Exclusive “closed-loop” boxed chainstay
*Aggressive race geometry

SPECS:

USE: Race

MATERIAL: 6061 aluminum

HEADSET STYLE: 1″ standard on Junior, Integrated 1-1/8″ 45°/45° on Expert and Larger

BRAKE MOUNTS: V-Brake

BB SHELL: Euro

TT: Top Tube | CS: Chain Stay | SA: Seat Angle | HA: Head Angle | H/S: Headset size

SIZE	TT	CS (center)	H/S	HA	SA	SEAT CLAMP	SEAT POST	WEIGHT
JUNIOR	18.5″	13.75″	1″ (standard)	72.5°	70°	1″ (25.4mm)	22.2mm	2.65lbs/1.2kg
EXPERT	19.5″	14″	1-1/8″ (integrated)	73°	71°	1″ (25.4mm)	22.2mm	3lbs/1.36kg
EXPERT XL	20″	14″	1-1/8″ (integrated)	73°	71°	1″ (25.4mm)	22.2mm	3.1lbs/1.4kg
PRO	21″	14.75″	1-1/8″ (integrated)	74.5°	71°	1-1/4″ (31.8mm)	27.2mm	3.7lbs/1.68kg
PRO XL	21.5″	14.75″	1-1/8″ (integrated)	74.5°	71°	1-1/4″ (31.8mm)	27.2mm	3.8lbs/1.72kg
PRO XXL	22″	14.75″	1-1/8″ (integrated)	74.5°	71°	1-1/4″ (31.8mm)	27.2mm	3.9lbs/1.77kg
PRO XL 24″	21.5″	15.75″	1-1/8″ (integrated)	73.5°	71°	1-1/4″ (31.8mm)	27.2mm	4lbs/1.81kg
